GitHub Actions simplify and automate workflows, but managing repetitive steps across multiple action files can become cumbersome. One powerful solution to this issue is using Composite Run Steps. In this guide, we'll explore how to leverage this feature to streamline and reuse blocks of steps within your workflows.
What are Composite Run Steps?
Composite run steps are a way to reuse common steps across multiple workflows. They are defined in a single file and can be used in any workflow file in your repository.
Use Case Scenario:
Let's say we have a project that builds and deploys a Node.js application. We want to run unit tests, integration tests, and end-to-end tests.
What's common between all these actions is the following:
- name: Checkout code
uses: actions/checkout@v3
- uses: action/setup-node@v3
with:
node-version-file: .nvmrc
- run: npm ci
- run: npm run test
- name: Checkout code
uses: actions/checkout@v3
- uses: action/setup-node@v3
with:
node-version-file: .nvmrc
- run: npm ci
- run: npm run lint
- name: Checkout code
uses: actions/checkout@v3
- uses: action/setup-node@v3
with:
node-version-file: .nvmrc
- run: npm ci
- run: npm run build
Creating a Composite Run Step
We all need to install project dependencies. Fortunately, we can create what's called a composite run step that can be shared among all these actions.
Step 1: Create a Composite Run Step
- Create a new file in your repository under
.github/shared/setup/action.yaml - Add the following content to the file:
# .github/shared/setup/action.yaml
name: "Setup"
description: "Setup Node.js environment and dependencies"
runs:
using: "composite"
steps:
- name: Checkout code
uses: actions/checkout@v3
- uses: action/setup-node@v3
with:
node-version-file: .nvmrc
- run: npm ci
Step 2: Include the Composite Run Step in Your Workflow
-
Commit and push the file to your repository
-
Now we can use this composite run step in any workflow file in our repository. For example, in our
test.yaml
# .github/workflows/test.yaml
name: "Test"
on:
pull_request:
branches:
- main
jobs:
test:
runs-on: ubuntu-latest
steps:
# This value should be quoted and a path to the composite action
- uses: "./.github/shared/setup"
- run: npm run test
Same thing in our build workflow file:
# .github/workflows/build.yaml
name: "Build"
on:
pull_request:
branches:
- main
jobs:
build:
runs-on: ubuntu-latest
steps:
# This value should be quoted and a path to the composite action
- uses: "./.github/shared/setup"
- run: npm run build
Step 3: Test Your Composite Run Step
Let's create a pull-request and watch these workflows run with the shared composite run step.
What Are the Benefits of Using Shared Composite Run Steps?
Simplicity: Composite run steps allow you to reuse common steps across multiple workflows, making them easier to read and maintain. Consistency: Ensures that common steps are consistent across multiple workflows, aiding readability and maintenance. One Place to Update: Updates common steps in one place.
Swapping Package Managers
For example, if I decide to swap package managers from npm to pnpm, I can update the composite run step, and it will reflect in all my workflows.
```yaml
name: "Setup with PNPM"
runs:
using: "composite"
steps:
- name: Checkout code
uses: actions/checkout@v3
- name: Install Node.js
uses: actions/setup-node@v3
with:
node-version: 16
- uses: pnpm/action-setup@v2
name: Install pnpm
with:
version: 8
run_install: false
- name: Get pnpm store directory
shell: bash
run: |
echo "STORE_PATH=$(pnpm store path --silent)" >> $GITHUB_ENV
- uses: actions/cache@v3
name: Setup pnpm cache
with:
path: ${{ env.STORE_PATH }}
key: ${{ runner.os }}-pnpm-store-${{ hashFiles('**/pnpm-lock.yaml') }}
restore-keys: |
${{ runner.os }}-pnpm-store-
- name: Install dependencies
run: pnpm install
Trade-offs
Like any abstraction in programming, there are trade-offs to using composite run steps that you should be aware of:
One Place to Break Them All: Given it's a shared step, if you break it, you break it for all workflows that use it. This is why it's important to test your composite run steps before pushing them to production. Complexity by Obscurity: It can be confusing for some developers to understand where the steps are being defined.
Conclusion
Composite run steps are a powerful feature of GitHub Actions that allow you to reuse common steps across multiple workflows, making them easier to read and maintain. Check out this repository for an example of how I use them for my open-source project mktable, and I hope you find this article helpful. Cheers!
